16 Teeth Starter Motor 41022010 497596 for Briggs & Stratton 14 16 18 HP V Twin With Free Gear
OEM Part Number: 497596 399928 393017 495100 498148 394674 394808 AM38984 435307 AM39287 498594 498595 SBS0009 5744N 5744 410-22010R 41022010R 410-22010 41022010
Starter Motor Replaces 498148 435307 497956 for Briggs Stratton V-Twin 14HP 16HP 17HP 18HP 18.5HP 19HP 20HP 21HP 22Hp Opposed Twin Cylinder Use On MTD Craftsman Cub Cadet John Deere Mower Tractor
BRIGGS& STRATTON: 393017 394674 394808 435307 497596 497956
JOHN DEERE: AM38984 AM39287
TYPE: PMDD
VOLTAGE: 12
ROTATION: COUNTERCLOCKWISE
TOOTH COUNT: 16
GEAR OD: 1.598IN / 40.6MM
MOUNTING EAR 1: 9.5MM UNTHREADED
MOUNTING EAR 2: 8.5MM UNTHREADED
MOUNTING EAR 3: 8.5MM UNTHREADED
SPECIFICATIONS: 3.8" / 96.5MM LONG FIELD CASE
SPECIFICATIONS: PLASTIC PINION GEAR
WEIGHT: 5.18 LBS / 2.35 KG
Fit For:
BRIGGS & STRATTON
ENGINES AIR COOLED 14HP HORIZONTAL
ENGINES AIR COOLED 14HP VERTICAL
ENGINES AIR COOLED 16HP HORIZONTAL
ENGINES AIR COOLED 18HP HORIZONTAL
Fits Briggs & Stratton models 400417, 400437, 400447, 400707, 400777, 401407, 401411, 401415, 401417, 401431, 401437, 401707, 402415, 402417, 402431, 402435, 402437, 402445, 402447, 402451, 402707, 402777, 404417, 404437, 404447, 404707, 404777, 40A777, 421417, 421431, 421437, 421707, 422431, 422432, 422435, 422436, 422437, 422442, 422445, 422447, 422707, 422777, 42A707, 42A777, 42B707, 42C777, 42D707, 42D777, 42E707, 42E777, 460707, 460777, 461707, 461777, 462707, 463707.
CUB CADET
1604 BRIGGS & STRATTON 16HP GAS 1985-1986
1606 BRIGGS & STRATTON 16HP GAS 1985-1986
580 BRIGGS & STRATTON 16HP 1982-1984
582 BRIGGS & STRATTON 16HP 1979-1984
1605 BRIGGS & STRATTON 16HP GAS 1985-1986
1610 BRIGGS & STRATTON 16HP GAS 1985-1986
JOHN DEERE
MISC. LAWN EQUIPMENT (BY ENGINES) VARIOUS MODELS BRIGGS & STRATTON 16HP
MOWERS - WALK BEHIND COMMERCIAL MODELS BRIGGS & STRATTON 16HP
MOWERS - WALK BEHIND VARIOUS MODELS BRIGGS & STRATTON 16HP
TRACTORS - LAWN 116 BRIGGS & STRATTON 1982-1985
TRACTORS - LAWN 116H BRIGGS & STRATTON 1983-1985
Replaces Model: this is aftermarket replace all Briggs & Stratton Air Cooled engines Horizontal 14 / 16 / 18 hp. model 422432 422435 422437 422442 422445 422447 422707 422777 42A707 42A777 42B707, I/c Turbo Cool 14Hp 16Hp 18Hp 19Hp 19.5Hp 20.5HP
Replaces Parts: 4497596 AM38984 393017 394674 394808 497956 399928 495100 498148 435307 AM39287.
